Gráfico de Comparação de Modelos

Informacoes Do Produto

Disponíveis em quatro modelos distintos da NVIDIA® Quadro® Plex é construído para atender às suas necessidades específicas.

	Quadro Plex 2200 D2 Two NVIDIA Quadro FX 5800 GPUs One NVIDIA Quadro G-sync board Up to 4 channels 64X SLI FSAA (max on single channel)
	Quadro Plex 2100 D4 Four NVIDIA Quadro FX 4700 GPUs One NVIDIA Quadro G-sync board Up to 8 channels 128X SLI FSAA (max on single channel)

	Quadro Plex 2100 S4 Remote Graphics System Four NVIDIA Quadro FX 5600 GPUs 1U Server Form Factor
	Quadro Plex 2200 S4 Remote Graphics System Four NVIDIA Quadro FX 5800 GPUs 1U Server Form Factor

NVIDIA Quadro® Plex
	2100 D4	2200 D2	2100 S4	2200 S4
Form Factor	Deskside or 3U Rackmount Kit	Deskside or 3U Rackmount Kit	1U Server	1U Server
NVIDIA Quadro GPU	Quadro FX 4700 X2	Quadro FX 5800	Quadro FX 5600	Quadro FX 5800
# NVIDIA Quadro GPUs	4	2	4	4
CUDA Processor Cores	512	480	512	960
Total Frame Buffer	4 GB (1GB/GPU)	8 GB (4GB/GPU)	6 GB (1.5GB/GPU)	16 GB (4 GB/GPU)
Option	Quadro G-Sync	Quadro G-Sync	N/A	N/A
Display Channels	8 dual-link DVI	4 dual-link DVI	N/A**	N/A**
DisplayPort		2
Key Features
SLI Mosaic Mode	Y	Y	N/A	N/A
Shader Model	4.0	4.0	4.0	4.0
NVIDIA® CUDA™ Parallel Computing Processor	Y	Y	Y	Y
Genlock/frame lock	Y	Y	N/A	N/A
Frame Synchronization	Y	Y	N/A	N/A
FSAA (Max per Channel)	128x SLI FSAA	64x SLI FSAA	32x FSAA	32x FSAA
Stereo	Y	Y	N	N
Product Specifications
Host Connection	PCI Express x8 or x16, Small Form Factor, Passive (10W)
Host Connection	2M (6.5 foot) NVIDIA Quadro Plex Interconnect Cable		0.5M or 2.0M Quadro Plex Interconnect Cable
Power	640W Max		1200W Max
Power	110/240 VAC autosensing worldwide power supply
Acoustics	40dB		Idle 45 dB, Max 72 dB
Form Factor	Tower Desktop (9.49" H x 5.94" W x 20.55" D) or 3U Rack Mount (3U H x 8.5" W x 20.55" D)		1U Rack Mount (1.75"H x 17.4"W x 31.0" D)
Weight*	18.6lb		~40.0lbs

maximum # of Quadro Plex per host = 2

*standalone weight

**Readback Via PCI-Express Gen 2.0
